IT IS IMPORTANT TO READ THROUGH THIS SHEET BEFORE INSTALLING THE Z-BODY
CONGRATULATIONS!!! This is the most advanced and revolutionary upgrade available
for the Automag family of paint game markers.
Wear proper eye protection when installing or disassembling any paint game marker.
INSTALLATION
Installation is very simple but here is a brief overview of what to do.
1.Be sure you have read the orignal owners manual for your marker to ensure you know the proper
way to disassemble your markers.
2.Remove any air source and any loader from the marker that may be attached
3.Disassemble your marker by removing the AIR Valve, the Trigger Frame and Body Rail.
4.Reassemble, your marker replacing the Z-BODY for the original body.
MAXIMIZING RANGE
The Z-BODY is designed to put a backspin on the ball. This causes the ball to fly straighter and further than anything
else on the market GalacticSystemz Z-BODY allows you to adjust the amount of backspin on the ball from no spin to so much
spin that the ball will actually climb in the air. ALL this is easily done by turning the dial on top of the body.
Turn the dial counterclockwise to decrease the backspin.
Turn the dial clockwise to increase the backspin. Ideally you want the ball to fly with a flat trajectory without having to arc the gun.
Turning the dial too much will cause the ball to climb. Though this is a good trick it is not recommended as adjusting the dial clockwise too
much can damage the pantented system.
We are not responsible for any damage done to the Z-BODY by over adjusting the dial.
IMPORTANT
It is known that turning the dial clockwise too much will damage the Z-BODY. We do not warranty any Z-BODY damaged in this way.
DO NOT OVER TIGHTEN THE DIAL!!! Only adjust the dial so the balls fly on a flat trajectory.
We will not warranty any body that dameged in this way or with any after market modifications done it.
RECOMMECDATIONS FOR ULTIMATE PERFORMANCE
A large bore barrel is a must. If the barrel is too tight you will notice the balls are very inaccurate and the range is not that much better.
With a proper large bore barrel the balls will reach 80 yards easily and accuracy will amazing.
The dial apparatus will need to be cleaned from time to time. Take a cue tip or paper towel with alcohol and rube the orange tip inside the body.
This will remove any oil, dirt or grime from the tip.
Quality of paintballs is important. Through our tests Proball, Powerball and Nelson performed excellent but Proball Platinum was the best.
you want to make sure the balls you are using are clean and free from oil and residue by cleaning them in acetone, paint thinner or denatured alcohol.
